Derek Kozel

Bits to Volts

Assembling the Big Dish

| Comments

I’ve wanted for some time to get involved in radio astronomy and Amateur Radio EME operating. The most significant blocker for either of these activities is having an antenna with enough gain to be able to receive very weak signals and the ability to point it easily and accurately.

This weekend myself and a coworker lifted the panels of the big dish into place.

Unfortunately the weight of the dish and angle of the mount means that there was a gap between the final panels.

Using a set of C Clamps we were able to pull the edges nearly together, but the bolt holes were offset by just over a centimeter.

The offset is probably resolvable just with some long bolts and a bit of coersion. Worse is that the center of the dish was pulled over an inch out of position. Given that the dish weighs in excess of 400 pounds without the metal bracing it would take a small crane or similar to even try pulling it into order. The lack of a crane is exactly why we assembled it piece by piece.

Tunneling Web Traffic Over SSH

| Comments

At times it is useful to have your web traffic originate from a remote location for testing or access to geofenced resources. During university it was very useful for accessing the library resources. At other times being able to have all traffic encrypted from a laptop to a remote location such as when on an unsecured WiFi network. I’ve used this a good number of times so here is the minimal steps.

Basic Quadcopter Build

| Comments

A long term desire of mine has been to build a multicopter. Three years ago I tried flying a model powered glider and it went like a stone in a pool. In hindsight a glider is very good at catching any breeze so was a poor choice for a beginner as it was pushed far away before I could get a grip on controlling it. a few trees and almost a window later it was put in a closet then given to Goodwill. A multicopter has a much shorter flight time, but far lower wind load and can be held stationary with little effort even without fancy additions like GPS.

Pelco Pan Tilt Head

| Comments

For some time I’ve been working on a setup for receiving from, and eventually transmitting to, satellites and other moving aerial targets such as high altitude balloons. The initial design was based off of the work done by the SatNOGS team, but ran into reliability issues when 3D printing a revised version of the helical antenna joints. Additionally the SatNOGS design is being iterated at the moment and their rotator design wasn’t complete. In searching for alternative elevation azimuth rotator designs a few options came up:

  • Build a SatNOGS style rotator from servos
  • Join two single axis satellite dish rotators
  • Use a manual pan tilt head such as the Quickset Herculese line
  • Buy a commercial two axis antenna rotator

Using an OpenPGP Card

| Comments

I bought an OpenPGP card earlier this year and created a new GPG key (2642D337) during IETF 89. I’ve been using that key to sign git commits, ssh, and sign/encrypt significant emails and files. However I locked the card on purpose while experimenting with it and then encountered problems unlocking and reloading it. Since then the card has been taking up space in my wallet. Yesterday I was lounging and decided to look at my GPG setup and get the card working.

Latex in Octopress

| Comments

Many of the topics I work with involve math left, right, and center. Being able to use is a big feature for me so here’s the solution I’ve come up with so far. Credit certainly goes to Dr Zac and Felix for their work getting Latex playing nice. I believe that Zac’s is the more correct solution given its use of the custom header file rather than modifying the default layout. However Felix has the fix for a bug in MathJax which otherwise turns the entire page white when viewing an equation’s source.

Project Bankruptcy

| Comments

Most engineers, and probably most people in general, will be familiar with how projects and tasks accumulate. Finishing university and moving three times in two months has pushed my todo list past the end of the page. I sat down today and wrote down everything I could think of that I wished, or was obliged, to accomplish in the next month and have to admit that some (many) of the project ideas that float through my head simply aren’t going to get done.
